NC247G+SD60W40A
3G 4G Sim Card WiFi 1080P IP Camera
|
Model |
WS-NC247G |
|
|
Video |
Sensor |
2.0megapixel. HI3518E+1/2.8" SONY307 Star Light CMOS. |
|
Video resolution |
Main stream: 1920x1080@25fps, 1280x720@25fps Sub stream: 640x352@25fps, 320x176@25fps |
|
|
Video compression |
H.264 |
|
|
Lens |
2.7-13.5mm 5X optical zoom auto focus lens |
|
|
View angle |
96°~26.2° |
|
|
Night vision |
4pcs array infrared LEDs, night vision distance 60m |
|
|
Alarm |
Motion detecting alarm |
Can set 4 independent detection region (1-100 sensitivity can be set) |
|
Alarm linkage |
Alarm send pictures to the mailbox, |
|
|
Alarm recording |
Support Micro SD card and PC client linkage alarm recording |
|
|
4G |
4G standard |
FDD-LTE/TDD-LTE |
|
EU 4G frequency range (Optional) |
B1(2100MHz), B3(1800MHz), B7(2600MHz), B8(900MHz), B20(800MHz), B38(2600MHz), B40(2300MHz), B41(2500MHz) |
|
|
Interface type |
Micro SIM card, Plug and play, no need to set |
|
|
Storage |
Micro SD card |
Support up to 128G micro SD card |
|
Recording mode |
Alarm record, timing record, |
|
|
Video playback |
Support APP, IE browser, remote client play and download the video |
|
|
PTZ |
Rotation angle |
Horizon: 0~300°, Vertical: 0~60° |
|
Horizontal speed |
12°/S |
|
|
Vertical speed |
12°/S |
|
|
Preset |
Support 8 preset points |
|
|
General specification |
Power |
DC12V 2A |
|
Operating environment |
Environment -20℃~+60℃(-4℉~+140℉), |
|
|
Waterproof level |
IP66 |
|
|
Product size |
150mm×90mm×125mm(L×W×H) |
|
|
Product weight |
1.0kg |
|
|
Package size |
225mmx205mmx120mm(L×W×H) |
|
|
Package weight |
1.3kg |
|
|
Reset button |
Support |
|
Solar Panel Specifications:
|
Solar panel |
Peak power(Pmax) |
60W |
|
Peak voltage(Vmp) |
18.17V |
|
|
Peak current |
3.8A |
|
|
Short circuit power supply |
1.83A |
|
|
Solar cells |
36PCS mono crystalline silicon(125x41.66mm) |
|
|
Max System Voltage |
1000V DC(IEC)/600V(UL) |
|
|
Weather Proof Level |
IP 65 |
|
|
Operating temperature |
-40℃~+85℃ |
|
|
Solar panel size (mm) |
670*630*25 |
|
|
Battery type |
Lithium iron phosphate battery |
|
|
Battery capacity |
40AH |
|
|
Operating voltage |
8.25~12.6V |
|
|
Continuous current |
≤20A |
|
|
Instantaneous current |
50A |
|
|
Charging voltage |
12~12.6V |
|
|
recharging current |
0.5~10A |
|
|
Interface line |
Discharge: T type / charge: DC type |
|
|
Cycle life |
1000 times |
|
|
Operating temperature |
-20℃~+60℃ |
|
|
Battery weight |
2.5kg |
|
|
Battery size(cm) |
33x5.5x7.5 |
|
|
safety |
Overcharge protection, over discharge protection, short circuit protection, excessive current protection |
|
|
General specification |
Bracket material |
iron |
|
Installation |
Rack mounting |
|
|
Size(W×D×H)(mm) |
730*590*280 |
|
|
Weight(kg) |
17kg |
What are the Main Features?
* ALL 3G 4G available ,FDD-LTE, TDD-LTE, WCDMA/HSPA+, TD-SCDMA, GSM/GPRS/EDGE
* Professional senior Industrial level Main Board
* 2.7-13.5MM 2 Mega pixels Varifocal Lens ,5X Optical zoom
*60W single crystal solar panel, 40Ah12V lithium battery
* Standby recording about 3~4 days even cloudy or rainy
* H.264 Compression,dual stream(1.3MP), three stream(2.0MP)
* 4pcs array IR LED ,IR distance: 60M
* Built-in Micro SD card slot, Max 128G
* Support mobile phone remote view, compatible with many smartphone operating platform
* Support alarm pictures to send E-mail,upload to FTP server
* Support timer captured picture uploaded to Micro SD card and FTP server
* Built-in webserver to facilitate the user to use the standard IE browser to achieve the front end of the real-time browsing and setting management
*Support multi-screen viewing, playback, recording and alarming on PC.
